Observation System

GECKO PAN-TILT OBSERVATION SYSTEM

OUR GECKO PAN-TILT SYSTEM PROVIDES STRONG PERFORMANCE AND OPERATION SIMPLICITY. THIS SET HELPS YOU WITH ANIMAL AND DANGER DETECTION THANKS TO 360° SWIVEL RANGE AND APP CONNECTION.

STRONG PERFORMANCE

The compact and feature-oriented design, as well as the 2-axis control system via app and remote control, makes the GECKO 35 pan-tilt system an indispensable part of any standard equipment for hunters, boaters and the security industry

SIMPLE TO USE

Thanks to sensor-controlled and stabilized 360 degree rotation and 55 degree tilt range the system allows accurate detection of any movement within the radius of its own location.

PRECISION AND RESILIENCE

Gecko 35 Pro has 12μm thermal imaging detector with a 640 x 512 sensor resolution, a 35 mm focal length, a built-in digital compass and a motion sensor or replaceable battery pack, a diopter adjustment, and ergonomic controls. The device is supplied with a quickly removable 18650 Li-ion battery pack, which enables the device to be used for up to 6h.

ULTRA CLEAR MODE FOR HARSH CONDITIONS

For a better visual experience, Gecko 35 Pro supports cold and warm image hues. With the cold hue setting the device performance is for a clearer imaging quality with rich details and highlight targets. The warm hue setting generates softer imaging to avoid eye fatigue brought by long time usage.

PICTURE IN PICTURE (PIP)

The PIP function enables you to view a magnified digital zoom image in a separate ‘window’ simultaneously with the main image.

SAVE THE INTERESTING MOMENTS

Gecko 35 Pro thermal imager is equipped with a function for video recording and photographing an observed image onto the 32GB built-in memory card. Together with the system application it allows you to have an enhanced surveillance experience.

REMOTE CONTROL

The system is equipped with Bluetooth joystick (mini remote control) that fits comfortably in the hand and can be charged via USB. This allows the user to be controlled via the remote control or app.

APP

Find the APP in Google Play and the Apple store.

How to use the app?

1. Switch on the Wi-Fi function of the device Gecko 35 Pro.
2. With your Android device find the Wi-Fi network of the device named Gecko 35 Pro_XXXXX-XXXXXX, where the “X” are letters and numbers.
3. Connect with the Gecko device. The initial password is: 12345678
4. With ViewFinder from the App, you can live stream the scenes from your Gecko 35 Pro to your Android device.

SENSITIVE LENS

35 mm focal length with high quality germanium lens

COMPACT SIZE

Dimensions 160x90x50mm, Weight ≤400g

EXTENDED BATTERY LIFE

Up to 6 hours of battery life

EASY TO USE

pictogram menu for quick operation

UP TO 1820 M

of long-range of detection

800 M LRF

built-in laser rangefinder for distances reading

VIDEO RECORDER

32GB built-in storage space

WI-FI READY

to wirelessly stream on your phone or tablet

IMAGE MODES

Gecko 35 Pro offers a variety of image modes for different environments, situations and personal preferences.

WHITE HOT

White Hot is a versatile choice for observing urban areas and shifting landscapes that displays warmer objects in white and cooler objects in black.

BLACK HOT

Black Hot displays warmer objects in black and cooler ones in white, which makes it a preferred mode among hunters and law enforcement.

RED HOT

Red Hot is a recommended mode for prolonged observation. The red-black image minimizes blue light emissions from the display and reduces eyes strain from extended usage.

HOT TARGET HIGHLIGHT

Increases contrast for better highlighting of the warm objects. Suitable for observing animals in bushes and birds, where we have vegetation, making it difficult to detect and locate objects.

IRONBOW

Suitable palette for recognition & identification of the objects in large open areas, helping to highlight warm objects that are colored in warm colors against the cold colors of the environment background.

RAINBOW

Even areas with different temperatures of an object are colored in different color shades, which increase the chances for recognition & identification.

USES

SURVEILLANCE, SECURITY

Gecko 35 Pro is an incredible asset for observing and securing large building sites and extended living areas.

OUTDOOR ACTIVITIES AND SPORTS

Gecko 35 Pro is the perfect addition to your equipment set for your outdoor hobbies as it will give you an upgraded sense of your surroundings by allowing you to navigate in the toughest atmospheric conditions.

NATURE OBSERVATION

Gecko 35 Pro is the perfect tool for the observing the migration and calculating the population of animals in extended areas. It can even ensure the security of livestock in farms during harvesting periods.

DISTANCES MEASURING

Gecko 35 Pro helps to determine the exact distance to the spotted object.

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATION	NITEHOG GECKO 35 PRO
Micro bolometer	uncooled
Resolution, pixels	640×512
Pixel size, um	12
Sensor NETD, mK	≤35
Frame refresh rate, Hz	50
Objective Lens	F35/1.0
Field of view, m/100m	22.08
Optical magnification, x	3.4-13.6
Digital zoom, x	1/1.5/2/2.5/3/3.5/4
Minimum focusing distance, m	1
Focusing range of eyepiece (diopter)	-5D~+5D
Detection Range, m (Target size:1.7m×0.5m, P(n)=99%)	1818
Display Type	OLED
Display Resolution, pixels	1024×768
Battery Type	Li-ion battery pack
Max. battery life (t=25℃) ★, h	≈6
Laser rangefinder range, m	800±1
Amount of built-in memory, GB	32
APP compatibility	supported
Dimension, mm	160x90x50
Weight, g	≤400
IP code	IP67
Operation temperature，°C	-20+50

OUR GALLERY

SEE GECKO 35 PRO IN ACTION

GECKO OBSERVATION SYSTEM

GECKO 35 PRO – PRODUCT PRESENTATION

GECKO 35 PRODUCT REVIEW

WHAT’S IN THE BOX

To ensure your utmost experience with our product Gecko 35 Pro comes bundled with: portable bag, type C USB cable, HDMI cable, power adapter, battery charger, hand strap, neck strap and lens cleaning cloth.
